Configuration Nodes and Keys

Path: / (Root of node)

Key	Type	Default Value	Description
preferences.imported	LocalDateTime	is stored by the kernel	Subtrees of the Java Preferences can be exported and imported. The kernel exports the subtree of the current node to the storage directory at startup. When starting up a new node, a subtree can also be imported. The time of the import is saved here.

Path: kernel.configuration

Key	Type	Default Value	Description
node.id	String	mandatory	The node ID.
segment.id	String	mandatory	The segment ID.
config.name	String	The node ID if empty	The name of the configuration. The name can be different from the node ID. For client nodes, the node ID can have a wildcard, e.g. "MyClient-*". The asterisk is changed by the system to a random string. To avoid that now always new configuration entries must be stored under this configuration name, you can specify a different configuration name, e.g. "MyClient". All client nodes will then access the same configuration.
node.description	String	empty	A brief description of the node, its tasks, location, etc.
storage.dir	String (A directory path)	empty	In this directory plugins store their data. The kernel will usually only store an XML file that contains the configuration of the node. This file can be modified and used as a configuration file for new nodes.
type.of.node	String (see ETypeOfNode)	mandatory	The type of node. Server nodes require a different license than client nodes. Tools do not require a node ID because they do not network.
vendor	String	empty	"sillysky.net", or your company.
license	String (UUID)	mandatory for SERVER and CLIENT	You will get a license from us. See here.
base.dir	String (Path)	optional, if empty then current directory	A base directory is used to create non-configured other directories relative to it, e.g. "log", "storage" and "config" directory.
log.dir	String (Path)	optional, if empty "log" relative to base directory	The directory where the log files are created, if not configured otherwise.
plugin.dir	String (Path)	empty (default: plugins)	The directory where the plugin JARS are located.
dump.properties	Boolean	false	True: The system properties (System.getProperties()) are printed at start-up.
preference.import	String (path of file)	no default	Subtrees of the Java Preferences can be exported and imported. The kernel exports the subtree of the current node to the storage directory at startup. When starting up a new node, a subtree can also be imported. The path of the file is saved here.
preference.tcp	String (IP:port)	empty	If a TCP address with port is entered here, the configuration can be loaded from a central server. On the server node the plugin NY_ConfigurationProvider is executed, which offers the configuration file via a TCP server. The key for the correct file is of course the configuration name.

Path: network/configuration.provider

Key	Type	Default Value	Description
server.port	int (port)	empty (default: 28346)	The port of a TCP server for distributing configuration files. See NY_ConfigurationProvider.
connection.input.buffer.size	int	empty (default: 2100)	The size of the input buffer. See NY_ConfigurationProvider.

Path: tcp/server/YOUR_SERVER_NAME

The server names can be any.

Key	Type	Default Value	Description
id	UUID	any	Any UUID.
port	int	any	The server port.
input.buffer.size	int	270000	Optional: The size of the input buffer.
tls.enabled	boolean	false	Optional: True: TSL is enabled. A keystore and a truststore must be specified via command line. See: How nodes are connected to each other See: NY_TcpPlugIn
tls.protocols	String	TLSv1.3	Optional: A list of TLS protocols, comma separated.
tls.cipher.suites	String	TLS_AES_128_GCM_SHA256	Optional: A list of TLS cipher suites, comma separated.

Path: tcp/server/YOUR_CLIENT_NAME

The client names can be any.

Key	Type	Default Value	Description
id	UUID	any	Any UUID.
input.buffer.size	int	270000	Optional: The size of the input buffer.
tls.enabled	boolean	false	Optional: True: TSL is enabled. A keystore and a truststore must be specified via command line. See: How nodes are connected to each other See: NY_TcpPlugIn
tls.protocols	String	TLSv1.3	Optional: A list of TLS protocols, comma separated.
tls.cipher.suites	String	TLS_AES_128_GCM_SHA256	Optional: A list of TLS cipher suites, comma separated.
host	int/String	any	The server host address.
port	int	any	The server port to connect.
retry.timeout	int	0	Optional: The time in milliseconds after the client retries to connect the server. The value 0 means that no further attempt will be made.

Path: logging/writer

Key	Type	Default Value	Description
Sub-nodes, The name doesn't matter			Sub-nodes that configure individual LOG writers can be stored in this node. The name of the sub-nodes does not matter, e.g. "file" or "console".

Path: logging/writer/NAME_OF_YOUR_WRITER

Key	Type	Default Value	Description
formatter.class.name	String (class name)	de.sillysky.nyssr.log.CDefaultMessageFormatter	A formatter for the output of the LOG messages by this writer.
level	String (log level)	INFO	The root log level.
writer.class.name	String (A log writer)	de.sillysky.nyssr.log.CDefaultConsoleLogWriter for console, or de.sillysky.nyssr.log.CSyncFileLogWriter for files	A writer that outputs messages to the console, writes them to a file, transports them over the network, or passes them to another LOG framework.
file.path	String (path)	log/MyNode.log	The path of a log file.

Path: logging/writer/NAME_OF_YOUR_WRITER/levels

Here the logger levels are configured.

Key	Type	Default Value	Description
A_LOGGER_NAME_OR_PACKAGE	String (log level)	e.g. network.costs	Any logger configuration for this writer.

Path: network

Key	Type	Default Value	Description
message.protocol	String (MESSAGE or JSON)	default: MESSAGE	The message protocol. For MESSAGE streamed data is used, for JSON the JSON format is used. The MESSAGE protocol is smaller and faster than the JSON format.
packet.builder.sequence	String (M, MZ, MZA, MA)	default: M	The default setting for packing a message (for this node). M stands for the message and is always in the first place. Z stands for ZIP: The message is compressed. A stands for AES: the message is encrypted.

Path: session

Key	Type	Default Value	Description
private.key.algorithm	String	default: RSA	This value is only used by the session plugin. It describes the algorithm of the private key with which session tokens are signed.
private.key.data	String	default: missing	This value is only used by the session plugin. It contains the serialized data of the private key with which session tokens are signed.
public.key.algorithm	String	default: RSA	This value is optional and is then used in each node. It describes the public key algorithm used to verify the integrity of the session token signature. If the value is missing, an RSA keypair is generated by the central SessionManager. The public key is then sent to the other nodes by message.
public.key.data	String	default: missing	This value is optional and is then used in each node. It contains the serialized data used to verify the integrity of the session token signature. If the value is missing, an RSA keypair is generated by the central SessionManager. The public key is then sent to the other nodes by message.
timeout.in.minutes	String	default: 30	This timeout refers to the maximum validity of session tokens.
key.aes.storage	String	default: missing	Optional: If available, the session manager saves the session tokens in a file that is encrypted with this secret key during a reboot. If the value is missing, all sessions become invalid when the node is rebooted. The algorithm used is “AES”.

Path: network/costs

Normally, the cost of routing a message between two nodes is calculated from the ping times. Here the cost of certain connections can be set directly. This can be used to artificially increase the price of certain routes so that they are only used if no alternative exists for them. The key for the entries is the connection (in the notation NODE1::NODE2). The alphabetically smaller node should be in front (e.g. atlas::zulu instead of zulu::atlas). The value corresponds to the desired ping time (cost).

Key	Type	Default Value	Description
earth::moon	int (Ping time = cost)	mandatory	In the following example, each key-value pair is a separate entry: earth::moon = 50 earth::sun = 1 sun::venus = 30

Path: plugin.manager/plugins

A list of entries, where each entry is a plugin.
The key is any number you want.
Plugins are not loaded if the number is less than or equal to 0.
The entries are sorted by the keys.
The smallest key greater than 0 is loaded first, the highest key last.
The version number and extension can be omitted.
The highest version is then always loaded.

Key	Type	Default Value	Description
e.g. 0001	int (any)	mandatory	In the following example, each key-value pair is a separate entry: 0001 = NY_NetworkPlugIn 0010 = NY_TcpPlugIn 0020 = NY_MicroServicePlugIn 0030 = NY_MicroServiceRegistryPlugIn

Path: logCatcher

Key	Type	Default Value	Description
maximum.number.of.saved.log.entries	int	empty (default: 10000)	The LOG Catcher is a kernel service which can save log messages even if the LOG framework has not been started up yet. This is regularly the case for the startup. The messages can then be delivered to applications such as LOG Monitor to gain insight into the startup period.
